| Combined Model | SDM1324-MMQ |
| Maximum workpiece width | 30—1300mm |
| Minimum workpiece length | 320mm |
| Workpiece thickness range | 6—100mm |
| Lifting motor | 1.1kw |
| Conveying motor | 2.2kw |
| Feeding speed | 5—20m/min |
| Working air pressure | 0.6~08Mpa |
| Total power | 26.98KW |
| Overall dimensions | 长2360mmX宽2050mmX高2300mm。 |
| Weight | 3000Kg |
Product Categories : CNC Flat Sand Press
